5-axis CNC Machining Services
JUNSION's 5-axis cutting services offer speed and freedom that can't be beat. JUNSION can make the best 5-axis machined parts because we have a lot of modern 5-axis CNC tools and a long list of materials they can use.
Our skilled workers and advanced production tools enable us to quickly create and make complicated parts that need to be made quickly. With top-notch tools, knowledge, and years of experience, JUNSION uses two great setups to make accurate, complicated parts.
What is 5-Axis CNC Machining?
5-axis CNC machining is a high-tech way to make things that lets the cutting tool move in five different directions at the same time. This feature is necessary to make complicated, high-precision parts more quickly and with fewer setups. 5-axis machining services are used by industries like aircraft, automotive, and medical device production to make very precise parts with a lot of moving parts.
Core Advantages:
- Complex Geometry Capability - Machine intricate parts with undercuts, angled features, and curved surfaces that traditional 3-axis machines cannot reach
- Superior Surface Finish - Achieve better surface quality with shorter cutting tools and optimal cutting angles, reducing post-processing time
- Reduced Setup Time - Complete complex parts in one setup, eliminating multiple repositioning steps and improving accuracy
5-Axis CNC Machining Capabilities
Our ISO 9001 certification shows that we fabricate 5-axis milled parts to meet the tightest tolerance requirements. Our standard tolerance for CNC-milled plastics is ISO-2768-m and ISO-2768-f for metals. Get high-quality and precise complex parts with top-notch dimensional stability.
| Description | |
|---|---|
| Maximum Part Size | 4000×1500×600 mm |
| Minimum Part Size | 5 x 5 x 5 mm |
| General Tolerances | Within ±0.002 mm |
| Lead Time | For standard operations, lead times can be as short as 2-3 days, while more complex projects might require up to 2 weeks. |
5 Axis CNC Machining Design Guidelines
| Recommended Size | |
|---|---|
| Minimum Feature Size | Minimum feature size should be no less than 0.5 mm in width or depth to ensure structural integrity. |
| Linear Dimension | Maintain a precision within ±0.005 mm for linear dimensions to ensure accuracy across the machined part. |
| Hole Diameters (not reamed) | Holes can be machined with diameters starting from 1 mm up to 40 mm without reaming for precision sizing. |
| Shaft Diameters | Shaft diameters should range from 2 mm to 300 mm, considering the tool accessibility and torque requirements. |
| Threads and Tapped Holes | Threads from M2 to M24 can be machined. Ensure to provide adequate relief at the bottom of tapped holes. |
| Text | Minimum text height of 1.5 mm with a depth of 0.5 mm for clarity after machining. |
Industry Applications
Aerospace Our aerospace machining focuses on high-temperature resistance components like turbine blades and structural brackets. We work with superalloys that maintain strength at 1000°C+, meeting stringent FAA and EASA requirements for commercial aviation.
Medical Medical CNC machining at JUNSION produces FDA-compliant implants and surgical instruments. Recent successes include titanium spinal rods with complex curvatures and custom knee replacement components, all meeting ISO 13485 medical device standards.
Automotive We machine precision engine components, transmission parts, and prototype housings for electric vehicle manufacturers. Our services support both traditional automotive and emerging EV technologies.
Electronics Custom heat sinks, precision enclosures, and antenna components for telecommunications and consumer electronics. We specialize in parts requiring electromagnetic shielding and thermal management.
Quality Assurance
Certifications:
- ISO 9001:2015 Quality Management
- AS9100D Aerospace Quality Standard
- IATF 16949 Automotive Quality
Quality Control Process:
- CMM Measurement - All precision tolerances verified using coordinate measuring machines with 0.001mm resolution. Statistical process control ensures consistent quality across production runs.
- Surface Inspection - Advanced profilometry equipment measures surface finish to Ra 0.8μm standards. Visual inspection under magnification catches any surface defects.
- Final Documentation - Complete inspection reports with dimensional data, material certificates, and surface finish measurements accompany every shipment.
Our quality team performs first-article inspection on all new parts and maintains real-time process monitoring during production. We guarantee full traceability from raw material through final delivery.
Success Stories
Aerospace: Commercial Aircraft Manufacturer Challenge: Complex titanium bracket with 15 angled holes requiring ±0.025mm positional accuracy + high-temperature resistance to 400°C Solution: Used Ti-6Al-4V with 5-axis simultaneous machining and specialized high-feed endmills Results: 60% reduction in machining time while achieving 0.015mm positional accuracy, exceeding requirements
Medical: Orthopedic Implant Company Challenge: Custom spinal implant with biocompatible surface + complex internal channels for bone growth Solution: Used medical-grade titanium with 5-axis contouring and specialized surface treatments Results: 100% FDA compliance with 50% faster production versus traditional methods
Automotive: Electric Vehicle Startup Challenge: Lightweight motor housing prototype + integrated cooling channels requiring rapid iteration Solution: Used aluminum 7075 with simultaneous 5-axis machining for complex internal geometries Results: 3-week prototyping cycle reduced to 5 days, enabling faster design validation
Electronics: Telecommunications Equipment Challenge: RF waveguide component + precision dimensional control for signal integrity at 60GHz frequencies Solution: Used brass alloy with 5-axis finishing passes for optimal surface conductivity Results: Signal loss reduced by 25% compared to assembled alternatives, meeting strict RF performance specs.
